1. Using GC2033 photosensitive film + GK7102C main control DSP chip, the performance is stable and reliable
2.H.264 compression format, mobile phone or PC computer 1080P 2 million HD monitoring and recording
3. Cloud server architecture, data storage in the cloud, no need to change the phone. Cloud servers all over the world, dual server backup architecture, more stable and reliable
4. Independently developed intelligent P2P penetration technology, strong penetrating ability, one-button remote, plug-and-play intelligent LED infrared anti-exposure function;
5. Echo cancellation and noise suppression technology, noise is completely eliminated when the pan/tilt is rotated, and high-fidelity call quality
6. Multiple recording methods: timer recording, motion detection alarm recording,
7. Multiple video storage: TF card\computer\mobile/cloud storage
8. Powerful night vision function: 1 dot matrix, infrared distance 10-15 meters
9. Automatically adjust camera APP language according to mobile phone language, support multi-language library
10. Cloud storage function
|
System |
Host processor |
Industrial embedded microcontroller GK7102C |
|
Operating system |
Embedded LINUX operating system |
|
|
Video |
Image Sensor |
2.0MP CMOS |
|
Monitoring image quality |
1920*1080/640*360 |
|
|
Video Quality |
640*360 |
|
|
Image motion detection |
support |
|
|
Min illumination |
0.1LUX/F1.2 |
|
|
Grab function |
support |
|
|
Video Flip |
support |
|
|
Audio |
Coding Standards |
G.711 |
|
Audio Input |
support |
|
|
Recording Management |
Video mode |
Motion detection recording、Timer recording、Alarm recording |
|
Recordings storage |
TF card \ computer \ mobile phone\Cloud storage |
|
|
Remote Playback、download |
support |
|
|
Alarm is triggered |
Video Push、Speaker alarm、Alarm recording、grab、sending |
|
|
Net |
Wired Ethernet port |
RJ-45 10-100MB auto Adapted Ethernet interface |
|
wireless network |
802.11b/g/n |
|
|
Stream |
Dual-streaming |
|
|
NIV |
Private agreement |
|
|
P2P networking |
Smart P2P |
|
|
WIFI networking |
Ap direct connection |
|
|
Expend |
IR-CUT |
support |
|
Micro SD card |
Maximum support 64GB TF card |
|
|
WIFI |
support |
|
|
433MHz alarm |
Not support |
|
|
Lens |
3.6MM |
|
|
powered by |
power supply |
DC 5V 2A |
|
power |
5W |
|
|
condition |
Storage temperature |
0℃－＋55℃ |
|
Storage humidity |
10%－90% |
|
|
others |
Lens |
3.6MM |
|
Others |
Size |
35mm*105mm |
