1. Embedded RTOS design, dual-core 32-bit DSP (Hi3518E), pure hard compression, watchdog
2. Advanced H.264 video compression technology, ultra low bit rate, dual stream
3.100W HD resolution, clear and delicate images; support wireless
4. WIFI network connection, one button WPS function;
5. Support Micro SD card, maximum 32G;
6. Support 2D/3D noise reduction, digital wide dynamic;
7. Support a variety of cloud technologies, achieve network penetration, push alarm information to mobile phones and other functions;
8. Support all kinds of mobile phone remote monitoring (IOS, Android),
9. Support a variety of web browsers (IE, Chrome, Firefox, Safari),
10. Lightning protection, in line with national standards GB/T17626.5 international standard IEC61000-4-5;
11. Full-featured: PTZ control, alarm, one-button reset, etc.

Support Web side, CMS, central management platform software MYEYE, provide SDK development support multi-language

Parameter
System Architecture                Embedded RTOS Design, Dual Core 32-Bit DSP (Hi3518E), Pure Hard Compression, Watchdog
Sensor                                  1 million 1/2.8" low illumination CMOS sensor;
Color 0.01Lux@F1.2; black and white 0.001 Lux@F1.2
Video processing                    H.264 video encoding, support dual stream, AVI format; support stream 0.1M~6Mpbs adjustable;
Frame rate 1~30 frames/second adjustable
Image output                         mainstream: 1280*720;
Substream: 704*576
Shutter                                  1/50 (1/60) seconds to 1/10000 seconds
Lens                                      panoramic camera
Visible distance                      depending on the lens
Hardware function                  Support one-button reset function
Fill light                                 infrared fill light
Audio processing                    G.711 codec standard, support two-way voice intercom function, support audio and video synchronization
Noise reduction                      support 2D/3D noise reduction
Wide dynamic                         support for digital wide dynamics
Image Settings                       Saturation Brightness Contrast adjustable via client or IE browser
Storage function                      Support SD card Maximum 32G
Intelligent alarm,                     motion detection, video loss, network cable break, IP address conflict,
Support protocol                      Supports network protocols such as RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP
General purpose dual stream, heartbeat, password protection
Business function                    Support OSD, support real-time video transmission, support mobile detection, support mobile detection alarm, center
Wake up and screen pop-up linkage; support JPEG capture; support unified client remote monitoring soft
System applications such as MYEYE platform; provide a complete SDK development package;
Reliability                                Comprehensive lightning protection, in line with national international standards; 7*24 hours 65 °C high temperature                                              test is stable and reliable (including the whole machine test)
Audio interface                        Supports pickup input
Network interface                    Support wireless network connection, one-button WPS function
Working temperature              -10 ° C ~ 60 ° C
Power supply                         Power supply: DC5V,
Power consumption:               ≤3W
