| * Support P2P function | ||
| * 4.5" body construction,10X/20X/36X optional | ||
| * Compatible with CMS, UC2,Milestone and AXXON platform | ||
| * ONVIF2.4 ; Compatible with HIKVISION ,DAHUA, XM,Video park NVR | ||
| * Intelligent IR illumination & power consumption is variable, dependant the zoom factor | ||
| Specification | ||
| Camera | ||
| IPCM0043 | ||
| Sensor | 1/3" CMOS 4MP OV4689 | |
| Output Pixel | 2688x1520 | |
| Lens | 20X f=4.7mm~94mm | |
| BLC | Support | |
| AGC | Auto/manual | |
| WB | Auto/manual/indoor/outdoor | |
| DNR | 2DNR,3DNR | |
| WDR | DWDR | |
| S/N Ratio | ≥50dB | |
| Dome | ||
| Communications Protocol | TCP/IP,HTTP,NTP,IGMP,DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,HTTPS,P2P | |
| Software Control | IE, UC2, Management Platform | |
| Mobile View(optional) | Support Windows, iPhone platform smartphone | |
| Video compression | H.264/H.265/M-JPEG | |
| Audio compression | G711,PCM | |
| Rotation Range | Pan: 0°~360° , Tilt: 0°~93° | |
| rotation speed (optional) | Pan: 0~80°/s , Tilt:0~40°/s | |
| Auto Flip | Horizontal 180°, Vertical 93° | |
| Preset Points | 254pcs presets（dwell time 01-60s interval available） | |
| A-B scan | User programmabel(scan speed 1-64 levels setting available) | |
| Guard Tours | 3 groups( Max.16 points, dwell time user selectable) | |
| Operating temperature | -40℃~+60℃ | |
| Operation menu | English | |
| Power | DC 12V 3A | |
| Consumption | ≤25W | |
| Lightning Protection | Transient voltage 6000V | |
| Related validation | IP66,CE,FCC,RoHs | |
| IR parameters | ||
| Auto Control IR LED | PWM | |
| IR distance | Up to 60 meters | |
| LEDs |
BT-54F 6PCS Array 42Mil IR LED |
|
| Support ambient light detection | IR illumination on 1-9 grades selectable | |
