model
|
IPCM0062
|
Resolution
|
1280×960
|
|
Lens pixel
|
130W
|
|
Lens pixel
|
1.44mm viewing angle: 180°
|
|
PTZ adjustment angle
|
Electronic PTZ - Horizontal: 0°~180°, Vertical: -90° ~90°
|
|
Day and night conversion mode
|
IR-cut dual filter automatically switches
|
|
Minimum illumination
|
0.1 Lux @(F2.0,AGC ON), 0 Lux with IR
|
|
Video compression standard
|
H.264
|
|
Video compression stream
|
High-definition (1080P) smooth (VGA)
|
|
Audio source
|
Active microphone
|
|
Audio compression standard
|
G711A
|
|
Audio compression stream
|
Code stream adaptation
|
|
Communication Interface
|
1 RJ45 10M/100M adaptive Ethernet port
|
|
Wireless network protocol
|
Wi-Fi(IEEE802.11b)
|
|
Storage function
|
Support Micro SD card (up to 64G)
|
|
Infrared light illumination distance
|
5-10M (varies by environment)
|
|
Power consumption
|
3W（MAX）
|
|
Rated power supply
|
DC 12V 1A
|
|
Operating temperature
|
一10 ° C 一 50 ° C temperature is less than 95% (no condensation)
|
|
|
