| Resolution | 720P（1280*720） | |
| Chipset | 8135+1145 | |
| APP | Yoosee | |
| Lens | IR lens | 3.6mm mm(F:1.2 ) 3Mega Pixel lens |
| IR leds | 10 pcs ir leds | |
| IR distance | 10Meter | |
| Min. Illumination | Low illumination,0.1Lux@(F1.2 , AGC ON),0 Lux with IR On | |
| Audio | Input/Output | Built in Microphone, 3.5mm audio Jack output |
| Audio Compression | G.711, ADPCM/32kbps | |
| Image Compression | H.264 | |
| Light Frequency | 50Hz, 60Hz | |
| Image Resolution | 1MP | |
| Video | Image frame rate | 1~25fps |
| View | H.264 dual streaming | |
| Image adjust | The brightness, contrast, saturation, chromaticity, is adjustable | |
| White balance | Automatic, Indoor, outdoor , is adjustable | |
| Infrared mode | Automatic , manual (on/off) | |
| Supported Protocol | TCP/IP,UDP/IP,HTTP,SMTP,FTP,DHCP,DDNS,UPNP | |
| WIFI | Wireless Standard | WIFI(IEEE802.11b/g/n) |
| Data Rate | 802.11b: 11Mbps(Max.) 802.11g: 54Mbps(Max.) | |
| 802.11n: 150Mbps(Max.) |
