Camera model, parameters
|
model
|
TF1-X10Y
|
TF1-X20Y
|
|
|
model
|
1 million 1/4" network wireless smart camera
|
2 million 1/2.7" network wireless smart camera
|
|
system structure
|
XM510
|
XM510A
|
|
|
Camera pixel
|
720P
|
1080P
|
|
sensor
|
1/4" H62 CMOS sensor, color 0.1Lux@F1.2, black and white 0.01Lux@F1.2
|
1/2.7" SC2235P CMOS sensor, color 0.1Lux@F1.2, black and white 0.01Lux@F1.2
|
|
shutter
|
1/50 (1/60) seconds to 1/10000 seconds
|
1/50 (1/60) seconds to 1/10000 seconds
|
|
Lens
|
3.6mm-F1.4, horizontal vision 87°, diagonal 93°
|
3.6mm-F1.4, horizontal vision 87°, diagonal 104°
|
|
Lens interface
|
M12
|
|
Night light pattern
|
Infrared black and white night vision [automatic switching]
|
|
Infrared illumination distance
|
Within 30 meters
|
|
Compression format
|
Video compression format
|
H.264
|
|
H.264 encoding type
|
Main Profile
|
|
Video compression rate
|
HD, tag, second gear, rate adaptive
|
|
|
Maximum image size
|
Main stream: 1280*720; sub-stream: 640*360
|
|
Frame rate
|
Maximum frame rate: 50Hz: 25fps network frame rate adaptation
|
|
Features
|
Storage function
|
Support Micro SD card (up to 128G)
|
|
Alert function
|
Intelligent double light humanoid recognition alarm
|
|
Alarm mode
|
Siren warning, mobile APP alarm push
|
|
Two-way voice
|
stand by
|
|
Image flip
|
stand by
|
|
ONVIF protocol
|
stand by
|
|
Digital noise reduction
|
2D/3D digital noise reduction
|
|
supporting agreement
|
Xiongmai proprietary protocol supports the expansion of network protocols such as RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP
|
|
interface
|
Wired interface
|
1 RJ45 10M/100M adaptive Ethernet port
|
|
Storage interface
|
Micro SD card (up to 128G)
|
|
Wireless parameter
|
Wireless standard
|
IEEE802.11b, 802.11g, 802.11n
|
|
Frequency Range
|
2.4 GHz ~ 2.4835 GHz
|
|
General range
|
Power consumption
|
6W MAX
|
|
Product Size
|
190mm*100mm*75mm
|
|
Color box size
|
230mm*130mm*115mm
|
|
Working temperature and humidity
|
Zero 10 ° C -60 ° C, humidity less than 90% [no condensation]
|
|
power supply
|
DC 12V ± 10%
|
|
weight
|
Net weight: 435g Gross weight: 450g (Note: actual product)
|
