| Camera model, parameters | model | Small bald head 720P | Small bald head 1080P |
| model | 1 million 1/4" network wireless smart camera | 2 million 1/2.7" network wireless smart camera | |
| system structure | XM510 | XM510A | |
| Camera pixel | 720P | 1080P | |
| sensor | 1/4" H42 CMOS sensor, color 0.1Lux@F1.2, black and white 0.01Lux@F1.2 | 1/2.7" SC2235P CMOS sensor, color 0.1Lux@F1.2, black and white 0.01Lux@F1.2 | |
| shutter | 1/50 (1/60) seconds to 1/10000 seconds | 1/50 (1/60) seconds to 1/10000 seconds | |
| Lens | 3.6mm-F1.4, horizontal vision 87°, diagonal 93° | 3.6mm-F1.4, horizontal vision 87°, diagonal 104° | |
| Lens interface | F2.0 | ||
| Night light pattern | Infrared black and white night vision | ||
| Infrared illumination distance | Within 10 meters | ||
| Compression format | Video compression format | H.265X | |
| H.264 encoding type | Main Profile | ||
| Video compression rate | HD, tag, second gear, rate adaptive | ||
| image | Maximum image size | Main stream: 1280*720; sub-stream: 640*360 | Main stream: 1280*1080; sub-stream: 704*576 |
| Frame rate | Maximum frame rate: 25 frame rate adjustable | ||
| Features | Alarm mode | Siren warning, mobile APP alarm push | |
| Two-way voice | stand by | ||
| Image flip | stand by | ||
| ONVIF protocol | stand by | ||
| Cloud storage | stand by | ||
| Humanoid mobile tracking | not support | stand by | |
| Digital noise reduction | 2D/3D digital noise reduction | ||
| supporting agreement | Xiongmai proprietary protocol supports the expansion of network protocols such as RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP | ||
| interface | Wired interface | 1 RJ45 10M/100M adaptive Ethernet port | |
| Storage interface | Micro SD card (up to 128G) | ||
| Wireless parameter | Wireless standard | IEEE802.11b, 802.11g, 802.11n | |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz | ||
| General range | Power consumption | 3W MAX | |
| Product Size | 74*74*115mm | ||
| Color box size | 92*92*157mm | ||
| Working temperature and humidity | Zero 10 ° C -60 ° C, humidity less than 90% [no condensation] | ||
| power supply | DC 5V1.6A | ||
| weight | Net weight: 160g Gross weight: 280g (Note: actual product) | ||
