| Model | Hunting CAM | ||||||
| Highlight | ♦5 Mega pixels 1/2.5" Digital Camera | ||||||
| ♦1080P/25FPS video | |||||||
| ♦16 months Standby time | |||||||
| ♦20m range of IR flash | |||||||
| ♦Triggering time: 0.5 Second | |||||||
| ♦ 25m triggering distance | |||||||
| ♦Spray-water protected(IP protection class66) | |||||||
| Specification | |||||||
| Image sensor | 5 Mega pixels 1/2.5" Digital Camera | ||||||
| Still image size | 16MP:4608x3456;12MP:4000x3000;8M:3264x2448(interpolated);5M:2592x1944;3M:2048*1536; 1M:1280*960 | ||||||
| Video clip | 1920x1080/25fps；1280x720/30fps；720x480/30fps; 640x480/30fps;320x240/30fps | ||||||
| File format | JPG/AVI | ||||||
| Lens angle | f=3.62mm; F/NO2.0; FOV=70°; Auto IR filter | ||||||
| LCD Display | 2.4"TFT 720*320 | ||||||
| Memory | External memory(TF card, Class 6 Above, up to 32GB) / Internal memory(8Mx16 SDRAM) | ||||||
| Operation keypad | 8 Keys | ||||||
| The number of IR lamp | 2PCS High power | ||||||
| Range of IR flash | 20m | ||||||
| Triggering distance | 25m（ Below 77°F/25°C at the Normal Level） | ||||||
| Prep PIR sensing angle | 60° | ||||||
| Triggering time | 0.5 Second(When using the 4G TF card)； | ||||||
| Trigger interval | 5sec. - 60min;Programmable | ||||||
| Shooting numbers | 1-3; | ||||||
| Video Length | 3sec-10Minutes.; Programmable | ||||||
| Effectiveness | Daytine:1m-infinitive;Night time:1.5m-20m | ||||||
| Camera+Video | First take Picture then Video | ||||||
| Time stamp | On/Off;Include serial No.,temperatureand moon phase | ||||||
| Time lapse | On/Off; Time Lapse Programmable | ||||||
| Compressed video | TL Video Time Laps 3 Second ~ 24Hours | ||||||
| Endless Capture | On/Off; (On时，接近卡满时会删除最早的文档) | ||||||
| Target Recording Time | Time Laps 1 Second ~ 24Hours | ||||||
| Device serial No. | 4 digits or 26 alphabets set by yourself | ||||||
| Build-in Micophone/Speaker | Yes | ||||||
| Auto-distinguish images | Color images in daytime/black & white night images | ||||||
| Automatic screen saver | Automatic screen saver in 2 minutes while no keypad controlling | ||||||
| TV-out | Yes | ||||||
| PC interface | Mini USB2.0 | ||||||
| Power supply | 4xAA;Expandable to 8xAA，external 6V power supply,at least 1.5A | ||||||
| Standby time | approx.16 months | ||||||
| Lockable | Optional | ||||||
| Password protection | 4-Digit Numbers | ||||||
| Spray-water protected | Spray-water protected | ||||||
| Operating temperature | -7℃ to +40℃ | ||||||
| Storage Temperature | -20℃ to +60℃ | ||||||
| Dimensions & Weight | approx.136*90*72mm / | ||||||
