model
|
IPCM0210
|
|
Camera
|
Shape material
|
2.5" spherical, all aluminum alloy die casting
|
|
sensor type
|
Sony STARVIS 2 megapixel 1/2.8 IMX307 CMOS
|
|
Minimum illumination
|
0.001Lux @(F1.4,AGC ON) ,0 Lux with IR；
|
|
shutter
|
Shutter adaptive
|
|
Lens
|
4mm
|
|
PTZ angle
|
Level 0°-355°, vertical 0°-90°
|
|
Lens interface type
|
M12
|
|
Day and night conversion mode
|
Automatic, ICR infrared filter
|
|
Infrared illumination distance
|
30 meters (varies by environment)
|
|
Digital noise reduction
|
2D/3D digital noise reduction
|
|
Wide dynamic range
|
Digital wide dynamic
|
|
Compression standard
|
Video compression standard
|
Smart H.264
|
|
H.264 encoding type
|
Main Profile
|
|
Video compression code rate
|
Rate adaptation
|
|
Audio compression standard
|
AAC
|
|
Audio compression code rate
|
Rate adaptation
|
|
|
Image size
|
HD:1920X1080 SD:640x360
|
|
Frame rate
|
15 frames, network frame rate adaptation
|
|
Image setting
|
Mirror/flip
|
|
BLC
|
support
|
|
Network features
|
Intelligent alarm
|
Input: humanoid detection / humanoid tracking / humanoid tracking amplification Output: linkage custom audio / linkage lighting
|
|
One-click configuration
|
Smart configuration, AP configuration, manual addition
|
|
Interface Protocol
|
Cloud Private Agreement / ONVIF
|
|
General function
|
Anti-flicker, dual stream, heartbeat, mirroring, password protection, watermark
|
|
interface
|
Storage interface
|
Micro SD card (up to 128G)
|
|
Power interface
|
Φ5.5 round head power interface
|
|
Wired network port
|
support
|
|
Wireless parameter
|
Wireless standard
|
IEEE802.11b, 802.11g, 802.11n
|
|
Frequency Range
|
2.4 GHz ~ 2.4835 GHz
|
|
Channel bandwidth
|
support 20MHz
|
|
Safety
|
64/128-bit WEP， WPA/WPA2， WPA-PSK/WPA2-PSK
|
|
Transmission rate
|
11b:：11Mbps，11g ：54Mbps，11n ：150Mbps
|
