| Product name: | Internet network HD video camera |
| Product model: | IPCM0240 |
| Technical parameter | |
| Processor： | T10L+SC1245 |
| Platform: | 360eyes.club |
| Image sensor: | 1/4 HD CMOS 1 megapixel CMOS sensor |
| Manual video format： | MP4(1280*720P, storage in mobile) |
| Video compression standard： | H.264(Storge in TF card ) |
| Video frame rate: | Max 25 frame |
| Video playback mode: | Mobile client |
| Audio input and output: | Input： built in microphone; output： built-in speaker |
| Built in lens： | 3.6MM |
| Focusing method： | Manual |
| Infrared night vision effect: | 11pcs ir lights，night vision 10 meters，power consumption 1W；Control the ir light and IR-CUT switch through photoresistance |
| Focusing method: | Manual |
| PTZ control: | Horizontal rotation 355 degrees vertical 100 degrees |
| Local storage： | Support MicroSD inserted 128GB card, support 24 hours of video or video alarm |
| Cloud Storage： | Support |
| Support multiple protocols: | TCP/UDP、IP、HTTP、SMTP、DHCP、DDNS、UPNP、NTP |
| Wifi: | Support IEEE 802.11b/g/n |
| Video control: | Support |
| Motion detection: | Support |
| Human body tracking： | Support（optional） |
| Alarm action： | Mobile client push screenshot |
| Firmware upgrade: | Remote upgrade can be through the network |
| User settings： | Max share to 5 users |
| Supply voltage: | DC 5V1.6A |
| Working temperature: | 0 degrees C ~60 C |
| Working environment: | Indoor |
