Category

Types

Parameters

System

Operation

Embedded Linux OS

Online Visitor

Support 4 visitors at the same time

Image Capture

Image Sensor

1/2.7 inch 1080p Progressive Scan CMOS Sensor

Minimum Illumination

0.5Lux（color mode）,0.1Lux（black and white mode）

Lens/ View Angle

3.0mm@F2.4/155°Diagonal

Night Vision

Dual Filter,IR-Cut，8 pcs IR LED，IR irradiation distance:10M

Video

Compression standard

H.264 main profile@level:4.0/Motion-JPEG

Three-Stream

Main Stream：1080p（1920×1080）@15fps

Sub Stream：640*360@15fps

Third Stream：320*180@10fps

Rate/Maximum Frame Rate

128～4096kbps/25fps

Image Adjustment

Contrast,Brightness,Saturation, Hue

Audio

Input

Built in－38dB Microphone

Output

Built in 8Ω 1W speaker

Sampling Frequency/ Width

8KHz/16bit

Compression Standard /Rate

ADPCM/32kbps

Network

Protocols

TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc.

Wireless LAN

wifi802.11 b/g/n

Wireless Frequency

2.4~2.4835GHz

Wireless security encryption

64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption

Storage

Memory Card

Support T-Flash card maximum 128GB

Alarm

Alarm Detection

Support Motion Detection

Physical Environment

Input Voltage

110V~240V

Power

35W

Operating Condition

Temperature：-10～50℃

LED Light

Light Source

2 pcs of white LED light（4000-4500K）

Lumen

2*800Lm

Function

1. Remote lighting control (on/off/brightness)

2.Remote off alarm information

3. Motion detection and alarm (push message to APP )
