| Chip | CPU | GK7102 |
| Sensor | Sensor | SC2235 1/4‘ |
| Pixels | 1920×1080（2.0MP） | |
| Minimum illuminance | 0.02lux | |
| Lens | Lens/viewing angle | 3.6mm |
| View angle | 85° | |
| Night vision | Dual IR-CUT Filter auto switch | |
| IR distance | 10M | |
| Connect | Network Protocol | HTTP,FTP,TCP/IP,UDP,SMTP |
| DHCP,PPPoE,DDNS,UPnP，RTSP | ||
| Wired network | Support | |
| WiFi protocol | WiFi（IEEE 802.11b/g/n）2.4G | |
| Wireless Connect | SmartLink Connect | |
| Onvif | Support Onvif, RTSP | |
| AP Mode | Support | |
|
P/T Network |
Compression Format | H.264,MJPEG |
| Resolution | 1080P，640 x 480(VGA) | |
| Frame rate | 15fps | |
| Code Stream | Dual stream | |
| Motion Detection | Support | |
| Cloud storage | Support | |
| Automatic tracking | Support | |
| P/T | Pan:355°,Tilt:90° | |
| Recording | 24-hour loop recording. | |
| Storage | Local Storage | Max 128GB MicroSD card ;NVR;Cloud storage |
| Audio | Built-in microphone | Support |
| Compression format | G711A | |
| Internal speaker | Support | |
| physical characteristics | Power Consumption | DC5V/1.0A |
| Operating Temperature | -20°C ~ 60°C | |
| Operating Humidity | 20% ~ 85%, non-condensing | |
| Power dissipation | Max 5w |
