Specifications

IPCM0220

WIFI support system

IOS6.1 or above / Android 4.0 or above

support system

WIN/VIATA/MAC OS10.4

Video processing

H.264+/H.264 video encoding, support dual stream, AVI format; support stream adjustable 0.1M~6Mpbs; support frame rate adjustable from 1 to 30 frames per second

Image output

Main stream: 1920*1080@18fps; Substream: 704*576@25fps

shutter

1/50 (1/60) second to 1/10000 second

Lens

2.8MM/3.6MM

Day and night conversion mode

Support IR-CUT

Noise reduction

Supports 2D/3D noise reduction

Wide dynamic

Supports digital wide dynamics

Audio processing

G.711A codec standard, support two-way voice intercom function, support audio and video synchronization

Signal interface

1 photosensitive resistor interface, 1 IR-CUT drive interface, support the linkage of the photoresistor input signal with IR-CUT, infrared light

Human sensing

PIR infrared human sensor, support passive infrared sensor

WIFI antenna interface

1 WIFI antenna interface, support for wireless network connection, a key WPS function

Reset key interface

Supports one-button reset

SD card slot

stand by

reliability

Comprehensive lightning protection, in line with national international standards; 7*24 hours high temperature test at 65°C is stable and reliable (including testing of the whole machine)

ONVIF

NO

IR

10M

power

Power supply (optional): 1, DC5V; 2, 1 * 18650 power supply (support charging)

Attributes

Low power camera

other

Does not support any customization

weight

140g
