| system | P2P | support | |||||
| DDNS | support | ||||||
| Phone | Support Iphone、Android、windows、iOS | ||||||
| CMS | Support Windows，64CH viewing | ||||||
| MicroSD | Support alarm video recording, full-day video recording. | ||||||
| Network | Protocols | HTTP，UDP，SMTP，FTP，DHCP，DNS，NTP，UPnP | |||||
| Wired network | RJ45 10/100MB Adaptive Ethernet interface | ||||||
| WiFi | WIFI（IEEE 802.11b/g/n）2.4GHz | ||||||
| Wireless rate | 150Mbps(Max) | ||||||
| Maximum number of online users | Support 5 users online at the same time | ||||||
| stream | Support Dual-stream | ||||||
| lens | Lens type | HD glass lens | |||||
| Image Sensor | 1/2.7寸 CMOS Sensor | ||||||
| Image | 1920×1080（2.0MP） | ||||||
| HD Lens | 3.6mm | ||||||
| Viewing angle | 65° | ||||||
| IR-CUT | support | ||||||
| video | Video compression format | H.264+ | |||||
| Image frame rate | 1~25fps | ||||||
| Image resolution | Main stream:1080P(1920*1080)、 sub-stream:D1(704*480) | ||||||
| Image adjustment | Brightness, Contrast, Saturation, Sharpness | ||||||
| Minimum illumination | 0.4 LUX | ||||||
| Signal to noise ratio | >48dB | ||||||
| Audio | Audio compression format | G.726/G.711 | |||||
| Built-in microphone | support | ||||||
| speaker | support | ||||||
| PTZ | pan & tilt | Level: 355° & vertical: 90° | |||||
| IR | IR_CUT | Support | |||||
| Alarm | Alarm Detection | Motion detection Snapshot, audio/video record | |||||
| Alarm linkage | Support snapshot, audio / video | ||||||
| Alarm notification | Real-time App push notifications | ||||||
| characteristic | Material | plastic（ABS） | |||||
| Use environment | Indoor and outdoor | ||||||
| power | DC12V/ 2A | ||||||
| Work temperature | below zero 20°C～+50°C | ||||||
| Work humidity | 10%～80% | ||||||
| Box size | 201*201*120 | ||||||
| Others | Instructions, mounting brackets, mounting screws | ||||||
| Operating environment | Centralized monitoring of computer systems | Microsoft XP,Vista，Win7,Win8 | |||||
| IE | Internet Explorer6.0,7.0,8.0,9.0,10、Firefox, Google, Safari, etc. | ||||||
