*Full HD 1080p Battery Powered Security Camera with PIR Sensor(with Solar Panel for Continuous Power Charging Outdoor)
|
|
*The recharge battery can support 180 days standby, video intercom, infrared detection, fast response, easy installation.
|
|
* T20Z Chipset，More functions and lower power consumption
|
|
* Infrared night vision, guarding family safety 24 hours a day
|
|
* Intelligent motion detection, abnormal situation is pushed to mobile phone within 1second
|
|
* 2pcs 18650 rechargeable batteries, standby for up to 6 months
|
|
* 1080P 2.0MP high-definition picture quality, the picture is clearer and more delicate
|
|
* LinUX operating system, start faster, run more stable
|
|
* Wi-Fi/AP connection, no wiring required
|
|
* HD 2.0MP image sensors for recording clear dynamics
|
|
* Two wake-up methods: mobile phone remote active wake-up, PIR wake-up
|
|
* Support iOS and Android systems
|
|
Technical Parameters
|
|
Model
|
IPCM0191
|
|
Main Chip
|
T20Z
|
|
WIFI
|
WIFI 2.4GHz， IEEE 802.11 b/g/n
|
|
Sensor
|
2.0MP 1/2.9" CMOS Sensor
|
|
Lens
|
3.6mm@F2.0
|
|
Illumination
|
Minimum illumination black and white：0.01 Lux @ (F1.2,AGC ON)
|
|
lens Angel
|
80°
|
|
Led
|
2pcs Array IR Led ,15meters IR Disdance
|
|
SD Card Storage
|
8G/16G/32G/64G SD Card
|
|
PIR Motion Distance
|
3 to 8 meters
|
|
Mic
|
Built in Mic
|
|
Speaker
|
Built in Speaker
|
|
Battey
|
18650 2pcs，Rechargeable
|
|
Solar Panel
|
20,000 high performance dual crystal silicon
|
|
USB Power
|
5V DC ±10% 1000mA
|
|
Power consumption
|
≤1.5W
|
|
Operating Temperature
|
-10℃-＋60℃
|
|
Working humidity
|
10%-90% RH
|
|
Software
|
Operating System
|
LinUX
|
|
Upgrade Method
|
HTTP remote upgrade, external storage device upgrade
|
|
Video Decoding
|
|
1920*1080
|
|
Encoding format
|
H.264 video encoding compression
|
|
Frame rate
|
1080P@20fps
|
|
Audio Decoding
|
Decoding format
|
G.711a
|
|
Basic Features
|
Support mobile phone remote monitoring
|
IOS , Android
|
|
Video storage
|
SD Card Storage
|
|
Video
|
Recording duration can be configured, supporting local video recording and video on demand playback
|
|
Wake-up
|
Mobile remote active wake-up, PIR wake-up
|
|
Quick Startup
|
System startup within 1 second
|
|
Massage Push
|
Support PIR Massage Push
|
|
Motion Detectation
|
PIR motion ，Sensitivity High / Medium / Low Level adjustable
|
|
Night Vision
|
Night vision on/off function
|
|
Battery reminder
|
Low battery / normal / charging / full charge
|
|
Protocol
|
TCP/IP,HTTP,DHCP,DNS,NTP,P2P,SSL
|
|
Mobile APP
|
 Onecam
|
