3.8" 8x Hybrid Zoom ICSEE 8MP Dual Lens Cam Wireless Security Dome WiFi PTZ Camera

  • Model：IPCM0339
  • Description
3.8" 8x Hybrid Zoom ICSEE 8MP Dual Lens Outdoor Waterproof Cam Wireless Security Dome WiFi PTZ Camera With Alarm Light

Specification:
System Structure
Dual-core 32-bit DSP (NT98566), pure hard compression,watchdog
Sensor
4MP*2=8MP
Minimum illumination
Color: 0.01 Lux @ (F1.2, AGC ON); 0 Lux with IR; Black and white: 0.001 Lux @ (F1.2, AGC ON), 0 Lux with IR
Video Processing
H.265AI encoding, dual stream, AVI format; stream 0.1M~10Mpbs adjustable; frame rate 1~30 frames/sec adjustable
Image Output
Main stream: 2560*1440@12fps; Sub-stream: 800*448@12fps
Shutter
1/50 (1/60) second to 1/10000 second
Lens
2.8MM+12MM Combination of long focal length len + short focal length len
Day&Night Switching
Mode
Support IR-CUT
Noise Reduction
Support 2D/3D noise reduction
Wide Dynamic
Support wide dynamic
Auto Iris
none
Audio Processing
G.711A codec standard, support two-way voice intercom function, support audio and video synchronization
Audio Port
1 input, level 2Vp-p, impedance 1kΩ,; 1 output, impedance 16Ω, 30mw output power
Network Interface
1 RJ45 Ethernet interface, 10/100M adaptive
Signal Interface
1 photoresistor interface, 1 IR-CUT driver interface, support the linkage of photoresistor input signal with IR-CUT, infrared
light
PTZ Interface
1 horizontal motor interface, 1 vertical motor interface
Reset Key Interface
Support one-key reset function
Storage Method
Local TF card, maximum 128G; cloud storage
Comprehensive lightning protection, in line with national and international standards; 7*24 hours 65 ℃
Reliability
high temperature test is stable and reliable (including the whole machine test)
Intelligent Analysis
Support humanoid detection, support customization of other intelligent function
Business Functions
Support mobile client remote monitoring; support message push after humanoid detection and alarm; support MJPEG snapshot;
ONVIF
Support
Phone Monitoring
Support mobile phone monitoring (iOS, Android)
Power
DC12V
