Specification:
|
|
|
Resolution
|
2MP (1920*1080)
|
|
IR LED
|
2 pcs IR LED + 2 pcs White LED + 4pcs integrated Dual-light LED
|
|
Night Vision
|
25 m (82ft) Distance
|
|
Focal Length
|
3.6 mm
|
|
Field of View
|
93°(H), 48°(V), 115°(D)
|
|
Rotation range
|
355°Pan & -5~80°Tilt
|
|
Auxiliary Interface
|
|
|
Storage
|
SD Card Slot (MAX 128GB)
|
|
Audio Input/ Output
|
Built-in Mic & Speaker
|
|
Reset Button
|
Supported
|
|
Network
|
|
|
Wi-Fi
|
IEEE802.11b/g/n,50m Open Field
|
|
Ethernet Port
|
RJ-45 (10/100 Base-T)
|
|
Connection Way
|
Wi-Fi & IP
|
|
Max. User Access
|
5 Users
|
|
Mobile Operating System
|
OS, Android
|
|
Video & Audio
|
|
|
Video Compression
|
Smart H.265+, H.265, Smart H.264+, H.264
|
|
Frame Rate
|
Main stream: 1920*1080@25fps, sub-stream: 704*576@25fps;
|
|
Audio compression
|
Two way audio
|
|
AI function
|
|
|
Human Detection
|
Support
|
|
Rule Setting
|
Cordon / Alert Area
|
|
Show Traces
|
Support
|
|
Built-in Siren
|
Not Support
|
|
Light Mode
|
White Light / IR Light / Double Light
|
|
Customizable alarm Voice
|
Support
|
|
General
|
|
|
Power Supply
|
12 VDC, 2 A (camera price is not including power supply)
|
|
Power Consumption
|
< 24 W
|
|
Working Environment
|
–10° C to +45° C Less than 95% RH
|
|
Ingress Protection
|
Waterproof (IP66 Rated), Indoor & Outdoor Use
|
|
Material
|
Plastic ABS
|
